Hikvision DS‑3E1310P‑EI/M (O‑STD)
| Feature | Details |
|---|---|
| Brand | Hikvision |
| Model | DS‑3E1310P‑EI/M (O‑STD) |
| Device Type | 10‑Port Gigabit PoE Industrial Switch |
| Ports | 10 × 10/100/1000 Mbps RJ‑45 (8 PoE ports) |
| PoE Standard | IEEE 802.3af/at |
| PoE Power Budget | 120 W total |
| Switching Capacity | 20 Gbps full duplex |
| Forwarding Rate | 14.88 Mpps |
| Auto-Negotiation | Yes (supports 10/100/1000 Mbps full/half duplex) |
| MAC Address Table | 4 K entries |
| Power Supply | 12–48 V DC wide voltage input |
| Installation | DIN rail or wall mount |
| LED Indicators | Power, PoE, Link/Activity for each port |
| Operation Mode | Store-and-forward |
| Operating Temperature | −40 °C to +75 °C |
| Dimensions | Compact industrial design |
KSh 7,200.00
Safe Checkout
Description
The Hikvision DS‑3E1310P‑EI/M (O‑STD) is a high-performance 10-port Gigabit PoE (Power over Ethernet) industrial switch designed to deliver fast, stable, and reliable network connectivity in challenging industrial and commercial environments. With PoE support, full-duplex operation, and industrial-grade durability, this switch provides both data and power to devices such as IP cameras, wireless access points, and network terminals. Its compact and rugged design ensures reliable performance even in harsh conditions, making it an ideal choice for industrial facilities, transportation systems, and outdoor surveillance networks.
Whether deploying industrial surveillance systems or expanding small to medium industrial networks, the DS‑3E1310P‑EI/M guarantees consistent, high-speed performance for all connected devices.
Specifications Table
| Feature | Details |
|---|---|
| Brand | Hikvision |
| Model | DS‑3E1310P‑EI/M (O‑STD) |
| Device Type | 10‑Port Gigabit PoE Industrial Switch |
| Ports | 10 × 10/100/1000 Mbps RJ‑45 (8 PoE ports) |
| PoE Standard | IEEE 802.3af/at |
| PoE Power Budget | 120 W total |
| Switching Capacity | 20 Gbps full duplex |
| Forwarding Rate | 14.88 Mpps |
| Auto-Negotiation | Yes (supports 10/100/1000 Mbps full/half duplex) |
| MAC Address Table | 4 K entries |
| Power Supply | 12–48 V DC wide voltage input |
| Installation | DIN rail or wall mount |
| LED Indicators | Power, PoE, Link/Activity for each port |
| Operation Mode | Store-and-forward |
| Operating Temperature | −40 °C to +75 °C |
| Dimensions | Compact industrial design |
Industrial-Grade PoE Connectivity
The Hikvision DS‑3E1310P‑EI/M (O‑STD) provides 10 Gigabit Ethernet ports, including 8 PoE-enabled ports, enabling simultaneous data and power transmission over a single cable. Each port supports full-duplex operation, ensuring uninterrupted data flow for optimized network performance. With a total switching capacity of 20 Gbps, this switch guarantees stable, high-speed connections, even in demanding industrial or outdoor environments.
It is suitable for industrial IP cameras, wireless access points, network terminals, and automation devices, providing a reliable backbone for industrial networks and surveillance systems.
Plug-and-Play and Flexible Installation
Designed for ease of deployment, the DS‑3E1310P‑EI/M requires no configuration or software setup. Users simply connect devices with standard Ethernet cables, and the switch automatically negotiates speed and duplex settings. LED indicators display real-time status of power, PoE, and network activity, allowing users to monitor connectivity efficiently and quickly resolve issues.
Its compact industrial form factor allows flexible installation on DIN rails, wall mounts, or tight enclosures, making it ideal for industrial and outdoor network deployments.
Store-and-Forward Switching for Reliability
Operating in store-and-forward mode, the DS‑3E1310P‑EI/M ensures that only valid frames are transmitted, reducing network errors and improving overall reliability. The 4 K MAC address table efficiently supports multiple devices, making it perfect for industrial networks, surveillance systems, and automation environments that demand high-speed connectivity with PoE support.
Durable and Wide-Temperature Design
This Hikvision switch is built with industrial-grade components and a rugged casing, ensuring long-lasting operation in harsh conditions. Its wide operating temperature range (−40 °C to +75 °C) makes it suitable for extreme indoor and outdoor environments. The switch also features fanless, quiet operation, combining energy efficiency with reliable network performance.
Use Cases & Applications
The Hikvision DS‑3E1310P‑EI/M (O‑STD) is ideal for:
- Industrial surveillance networks
- Factory or warehouse network expansion
- Outdoor and transportation network setups
- Connecting IP cameras, wireless access points, and industrial terminals
- Harsh or wide-temperature environments requiring PoE
Its combination of PoE support, industrial-grade durability, and plug-and-play simplicity ensures a versatile and efficient solution for industrial and commercial networking.
Conclusion
The Hikvision DS‑3E1310P‑EI/M (O‑STD) is a 10-port Gigabit PoE industrial switch delivering high-speed, reliable connectivity with integrated power support. With plug-and-play setup, full-duplex operation, store-and-forward switching, and industrial-grade durability, it provides a compact and practical solution for industrial networks, surveillance systems, and harsh environment installations. Its combination of performance, robustness, and PoE functionality ensures efficient and dependable network operation.
