Hikvision DS-3E1518P-EI (O-STD) V2
| Feature | Details |
|---|---|
| Brand | Hikvision |
| Model | DS-3E1518P-EI (O-STD) V2 |
| Device Type | 18-Port Gigabit PoE Industrial Switch |
| Ports | 18 × 10/100/1000 Mbps RJ-45 (16 PoE-capable) |
| PoE Standard | IEEE 802.3af/at |
| PoE Power Budget | 240 W total |
| Switching Capacity | 36 Gbps full duplex |
| Forwarding Rate | 26.78 Mpps |
| Auto-Negotiation | Yes (10/100/1000 Mbps full/half duplex) |
| MAC Address Table | 8 K entries |
| Power Supply | 12–48 V DC wide-range input |
| Installation | DIN rail or wall mount |
| LED Indicators | Power, PoE, Link/Activity for each port |
| Operation Mode | Store-and-forward |
| Operating Temperature | −40 °C to +75 °C |
| Dimensions | Industrial compact form factor |
KSh 26,500.00
Safe Checkout
Description
The Hikvision DS-3E1518P-EI (O-STD) V2 is a professional-grade 18-port Gigabit PoE (Power over Ethernet) industrial switch designed to deliver robust, reliable, and high-speed connectivity across demanding industrial, commercial, and surveillance environments. With support for advanced PoE standards, full-duplex operation, and rugged hardware construction, this switch provides both data and power over a single Ethernet cable, simplifying installations and reducing wiring complexity. Its industrial-ready design ensures that performance remains consistent even under harsh environmental conditions.
This switch is an excellent foundation for modern network architectures where multiple PoE devices such as IP cameras, wireless access points, and automation controllers coexist. Furthermore, its combination of powerful throughput and dependable operation makes it suitable for network deployments in factories, warehouses, transportation hubs, and outdoor enclosures.
Specifications Table
| Feature | Details |
|---|---|
| Brand | Hikvision |
| Model | DS-3E1518P-EI (O-STD) V2 |
| Device Type | 18-Port Gigabit PoE Industrial Switch |
| Ports | 18 × 10/100/1000 Mbps RJ-45 (16 PoE-capable) |
| PoE Standard | IEEE 802.3af/at |
| PoE Power Budget | 240 W total |
| Switching Capacity | 36 Gbps full duplex |
| Forwarding Rate | 26.78 Mpps |
| Auto-Negotiation | Yes (10/100/1000 Mbps full/half duplex) |
| MAC Address Table | 8 K entries |
| Power Supply | 12–48 V DC wide-range input |
| Installation | DIN rail or wall mount |
| LED Indicators | Power, PoE, Link/Activity for each port |
| Operation Mode | Store-and-forward |
| Operating Temperature | −40 °C to +75 °C |
| Dimensions | Industrial compact form factor |
High-Performance PoE Connectivity
The Hikvision DS-3E1518P-EI (O-STD) V2 delivers 18 Gigabit Ethernet ports, including 16 PoE-enabled ports, enabling simultaneous data and power transmission over a single cable. Each port supports full-duplex operation, which allows simultaneous sending and receiving of data, maximizing network throughput. With a 36 Gbps switching capacity, this switch ensures smooth and stable connectivity, even when handling high volumes of traffic or multiple active devices.
Thanks to this capability, the switch is ideal for providing network support to IP cameras, VoIP phones, wireless access points, and embedded control devices across various industrial and commercial applications without compromising performance.
Plug-and-Play Industrial Deployment
The DS-3E1518P-EI (O-STD) V2 is designed for fast and simple deployment, requiring no configuration or software setup. Once network devices are connected with standard Ethernet cables, the switch automatically detects appropriate speed and duplex settings. LED indicators for each port provide immediate visual feedback on power, PoE, and connectivity status, making it easy for administrators to monitor network health and troubleshoot issues efficiently.
Additionally, the switch supports installation on DIN rails or wall mounts, providing flexibility in industrial racks, control cabinets, or outdoor enclosures where space and accessibility may be restricted.
Store-and-Forward Switching for Enhanced Reliability
Operating in store-and-forward mode, the DS-3E1518P-EI V2 verifies data packets before transmission, ensuring that only valid frames are forwarded to connected devices. This approach reduces network errors, improves data integrity, and enhances overall reliability. Meanwhile, the 8 K MAC address table efficiently supports large numbers of devices, making the switch suitable for large sensor networks, surveillance grids, or industrial monitoring systems.
Industrial-Grade Durability and Wide-Temperature Support
Built with industrial-grade components, this switch withstands harsh conditions and maintains performance across a wide operating temperature range (−40 °C to +75 °C). Its rugged enclosure and fanless design provide silent operation while minimizing maintenance requirements. As a result, the switch can perform reliably in environments such as factories, transportation hubs, outdoor installations, and distributed industrial facilities.
Use Cases & Applications
The Hikvision DS-3E1518P-EI (O-STD) V2 is ideal for:
- Industrial surveillance systems with numerous PoE devices
- Factory and automation networks requiring reliable Ethernet and PoE delivery
- Outdoor and remote installations in wide-temperature settings
- Commercial deployments with mixed PoE and non-PoE devices
- Transportation and utility monitoring systems
Its combination of PoE support, rugged build, and plug-and-play simplicity ensures dependable performance across all these scenarios.
Conclusion
The Hikvision DS-3E1518P-EI (O-STD) V2 is an 18-port Gigabit PoE industrial switch engineered for stable, high-speed, and reliable network connectivity with integrated power delivery. With plug-and-play setup, full-duplex operation, store-and-forward switching, and industrial-grade durability, it provides a comprehensive networking solution for surveillance, automation, and commercial systems. Its combination of performance, efficiency, and resilience ensures effective and long-lasting network operation in demanding environments.
